Teltonika RUT241 eSIM 4G LTE Cat 4, 3G, 2G Industrial Router, Compact Design, Wi-Fi Hotspot, 10/100 Ethernet, Secure VPN, Durable Metal Casing

£133.00 Exc. VAT

Teltonika RUT241 eSIM 4G LTE Cat 4, 3G, 2G Industrial Router

Category: Tags: , , , , , , , , ,

Industrial connectivity

Equipped with 4G LTE, Wi-Fi, and two Ethernet ports, RUT241 offers unstoppable connection continuity with automatic WAN failover. Industrial design, compact size, multiple connection interfaces, and compatibility with RMS make this device an excellent fit in numerous IoT and M2M solutions.

Hardware

Mobile 4G/LTE (Cat 4), 3G, 2G
CPU Mediatek, 580 MHz, MIPS 24KEc
RAM 128 MB, DDR2
Storage 16 MB, NOR Flash
Powering options 4-pin industrial DC power socket, 9 - 30 VDC
SIM 1 x External SIM holder (2FF)
Antenna connectors 2 x SMA for Mobile, 1 x RP-SMA for Wi-Fi
Ethernet 2 x 10/100 Ethernet ports: 1 x WAN (configurable as LAN), 1 x LAN
Wi-Fi IEEE 802.11b/g/n, Access point (AP), Station (STA)
Inputs/Outputs On 4pin socket: 1 x Digital input, 1 x Digital open collector output
Status LEDs 3 x Connection type, 5 x Signal strength, 2 x Ethernet, 1 x Power
Operating temperature -40 °C to 75 °C
Housing Aluminium housing with DIN rail mounting option, plastic panels
Dimensions (W x H x D) 83 x 25 x 74 mm
Weight 125 g
Supported frequencies 4G (LTE-FDD): B1, B3, B7, B8, B20, B28A; 3G: B1, B8; 2G: B3, B8

Software

Operating system RutOS (OpenWrt based Linux OS)
Mobile features Status, SMS, USSD, Black/White list, Multiple PDN, Band management, SIM PIN code management, APN, Bridge, Passthrough
Network features VoIP passthrough support, Network Management, Connection monitoring, Firewall, Firewall status page, Ports management, Network topology, Hotspot, DHCP, QoS / Smart Queue Management (SQM), DNS over HTTPS, DDNS, Network backup, Load balancing, SSHFS, VRF support
Security Authentication, Firewall, Attack prevention, VLAN, Mobile quota control, WEB filter, Access control
VPN and tunneling OpenVPN, OpenVPN Encryption, IPsec, GRE, PPTP, L2TP, ZeroTier, WireGuard, Tinc
Monitoring and Management WEB UI, FOTA, SSH, SMS, Call, Email, TR-069, MQTT, SNMP, JSON-RPC, RMS
Cloud solutions RMS, ThingWorx, Cumulocity - Cloud of Things, Azure IoT Hub
Services OPC UA, Modbus, Data to Server, Modbus MQTT GATEWAY, DNP3, DLMS

Additional information

Weight 1 kg
