Four Pole Base Mount Door Interlock Isolator Body – 40A
£53.00 Exc. VAT
Four-Pole Base Mount Door Interlock Isolator Body – 40A
For use with E69… Shafts and H69… Handles.
A range of door lock Isolators from IMO. Sizes are available from 20A to 100A. Isolator, Handle, and Shaft are supplied as separate parts.
Specification
Rated Thermal Current I: 40A
Rated Insulation Voltage U: 690V
Rated Operational Current I AC21A: 40A
Direct Switching of Single Motors 3×380-440V: 15kW
Cable Cross Sections: 0.5 – 10mm²
Size of Terminal Screw: M3.5
